ICI Dinkle Bus Bar Power Distribution Quick Connections Red Black Labeled Finger Safe 600V 20A 12-22AWG Marine Busbar Bussbar Buss 20 Positions
Product details
| Management number | 218151395 | Release Date | 2026/05/03 | List Price | US$12.00 | Model Number | 218151395 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Technical Data (UL) Rated Voltage: 600V Rate Current: 20A Conductor Cross-section, Solid (AWG): 22-12 Conductor Cross-section, Flexible (AWG): 22-12 Rated Impulse Withstand Voltage: 6KV Torque (N-m): 0.4 Screw: M2.5 Wire Strip Length: 9-11mm Insulating Material: PA TxHxW (mm): 5.1 x 39.6 x 40.5 (Individual Blocks) DIN Rail (mm): 35, 32 Jumper/Bridge: Press-fit/Insertion. These two assemblies include 5 DK2.5N-BK and 5 DK2.5N-RD Dinkle terminal blocks, 2 DSS2.5N-05P jumpers, 4 SS2 end brackets, 1 DK4NC-RD and 1 DK4NC-BK end cover, each mounted on a 3" piece of aluminum RoHS rail. The 5 black blocks are in common and the 5 red blocks are in common. Each assembly is labeled 1-10 with TM26W marking tags.
- Made in USA
- Finger Safe Bus Bar
- No Ring Terminals Necessary For Quick Install
- Elevator Cage
- Aluminum Mounting Base DIN Rail
- Each Bus Bar Handles Up To 20 Amps Total
| UPC | 737123111756 |
|---|---|
| Color | black, red |
| Gauge | 12.0 |
| Model | Dinkle-600V-20A-20P |
| Voltage | 600 Volts |
| Brand Name | International Connector |
| Part Number | Bus Bar Red Black 20A |
| Manufacturer | Dinkle |
| Material Type | Tinned Plated Copper Alloy Conductor, Zinc Plated Steel Screw and Elevator Cage, PA66 Insulation, UL94 Compliant |
| Mounting Type | DIN Rail Mount |
| Connector Type | Screw |
| Current Rating | 20 Amps |
| Number Of Poles | 5 |
| Centerline Length | 40.5 Millimeters |
| Specification Met | RoHS, UL |
| Number Of Contacts | 10 |
| Number of Positions | 20 |
| Item Dimensions W x H | 1.59"W x 1.56"H |
